Screened Separable Connector Plug On
Connectors for connecting underground cables to RMU’s, switchgear and transformers
TE Connectivity’s (TE) Raychem Screened separable T-connectors RSTI-58 are designed to connect single and three-core polymeric cables to medium voltage gas insulated switchgear and other equipment using bushings type “C” (EN50180/EN50181) specified for 630/1250A up to 24 kV.
Made of a highly modified silicone rubber and protected by a thin-walled, grounded outer conductive screen, TE’s Raychem RSTI-58 connectors are equally suited for indoor and outdoor installation. Supporting a wide application range, the design incorporates one body and stress cone adapters to cover any cross-sections from 25 mm2 to 300 mm2. The overall cut-back dimensions are designed to take up minimum space in the terminal box.
