Bluetooth Meter

1-Phase Bluetooth Electricity Meter

Product successfully added to the Quote List

The meter is a Class 1.0 Accuracy electric energy metering instrument with the high manufacturing technology to realize the measurement and control of active energy, and it supports the standard DLMS/COSEM specification, to realize the interoperability under master station. The meter mainly includes measurement unit, display unit, button unit, real-time clock unit, function of infrared and Bluetooth communication with other auxiliary ports that can be programmable.

TECHNICAL DATA

Full Product Specifications

Model	N21
Communication Type	Bluetooth
Normal voltage	230VAC
Normal frequency	50 Hz
Current rating	10(100) A
Measurement rating	Class 1.0 kWh, Class 2.0 kVarh
Operating temperature	– 25°C ∼ +60°C
Storage temperature	– 40°C ∼ +85°C
Insulation voltage	4 kV
Impulse voltage	10 kV
Calendar type	Gregorian
Display type	LCD – Liquid Crystal Display
